Specifications

CPU	NXP i.MX 6SoloX Cortex A9 1GHz Cortex M4 200MHz
GPU	Vivante GC400T
Storage	eMMC 4GB/8GB/16GB micro SD
RAM	DDR3L 1GB
Display	Parallel RGB 1080p60 Capacitive Touch Resistive Touch
USB	Host - Type A Device - Type mini-B
Network	Ethernet 10/100 Wi-Fi 2.4GHz Bluetooth v4.2
Can-Bus	Can 2.0 with transceiver
RTC	On board battery
I/O	UART 3x SPI I2C
Temperature Range	0 to 70°C (-40 to 85°C Optional)
Dimensions	4.0" x 4.0"

Documentation

Product Brief
Datasheet

Schematic and Assembly drawing available upon request
